Best Vial Plastic Tube Filling and Sealing Machine ZHF-1980N Company

Tube filling and sealing machine ZHY-60YP Supplier  compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Zungwan summarizes the defects of past products, and continuously improves them. The specifications of Tube filling and sealing machine ZHY-60YP Supplier can be customized according to your needs.The plastic tube filling machine with tube sealer is suitable for filling liquid and viscous products into plastic tubes, and seals filled plastic tubes. At the same time, this tube filler Sealer machine is also applicable to printing lot codes and the production date on the tubes. The plastic tube filling machine with tube sealer is mainly used for large diameter plastic tubes and laminated tubes, these tubes can be used for medical and pharmaceutical packaging, food products, cosmetics packaging and binder packaging.Automatic tube filling and sealing machine is widely used in the industries of toothpaste, cosmetics, pharmaceutical and foodstuff. The machine is automatic for its finding mark, sealing, printing lot number and tube out automatically.Model: ZHY-60YPBrand: ZUNGWAN

Multi-color fillingSpecial tube fillingSpecial-shaped sealing Compact design and auto tube feed. Driving part fully-closed.Tube washing and feeding marking identification, filling, folding, sealing, code printing and finished product output all conducted by a fully auto control system.Tube washing and feeding conducted pneumatically, accurate and reliable. Key Features Compact DesignDriving Parts Fully-closedPneumatic Tube Washing & FeedingIntelligent Temperature Control and Cooling SystemEasy to Operate and Adjust316L Stainless Steel Contact Parts to meet GMP StandardSafety Interlock Shutdown when Door is OpenOverload Protection ProvidedAutomated Working process from Tube Loading to Finished Products OutputAutomatic Orientation Effected by Photoelectric Induction Optional DevicesChillerDate Coding EmbossingAutomatic Tube Feeding MagazineChange Parts  Technical ParametersFilling volume: 1-400ml/unit (Adjustable)Filling accuracy: ≦±0.5﹪Capacity: 4000-4800unit/hour, AdjustableTube diameter: Φ10-60 mmTube length: 50-240mmHopper volume: 40LPower: 380V/220V (Optional)Air pressure: 0.4-0.6 MPaMachine power: 9kw

Key Features ◆Compact Design◆Driving Parts Fully-closed◆Pneumatic Tube Washing & Feeding◆Intelligent Temperature Control and Cooling System◆Easy to Operate and Adjust◆316L Stainless Steel Contact Parts to meet GMP Standard◆Safety Interlock Shutdown when Door is Open◆Overload Protection Provided◆Automated Working process from Tube Loading to Finished Products Output◆Automatic Orientation Effected by Photoelectric Induction Optional Devices◆Chiller◆Date Coding Embossing◆Automatic Tube Feeding Magazine◆Change Parts Technical ParametersFilling volume：1-120ml/unit (Adjustable)Filling accuracy: ≦±1﹪Capacity: 2400-3600units/hour (Adjustable)Tube diameter: Φ10-28 mmTube length: 50-180mmHopper volume: 40LEquipped motor: 1.1KW:Machine power: 2kwDimension: 1950×750×1850（mm）Power supply: 380/220 (Optional)Weight: About 900 Kg

Key Features  ZHF-160 tube filling & sealing machine is provided with 2 filling heads and a set of double-branch tube feeing system.Applicable to: plastic composite tubes , aluminum plastic composite tubes and metal tubes(optional) Optional Devices ◆Externally allocated refrigerator◆Special-shaped sealing devices (wave type sealing device, arc sealing device, T-shaped punching  hole sealing device, metal pipe folding and sealing device)◆Jacket and barrel heat preservation device◆Blending device inside the barrel◆Blowing and sucking type tube cleaning device◆Nitriding device before and after filling◆Automatically controlled material feeding device (pump)◆Finished tube conveyor Technical ParametersOper ation speed：160/min/(max)Filling volume：1-300mlFilling precision：≦±0.5﹪Suitable tube length：50-240mmSuitable tube diameter：10-50mmPower supply：380Volt, 50Hz  (220Volt, 60Hz)Power of hot-wind generator：3Kw×2Consumption of compressed air： 1.2 m3Working pressure：0.6 MpaCapacity of hopper：70LDimensions：2870×1770×2340mm

ZHDF-160B The automatic tube filling and sealing machine is mainly used to filling ointment or viscous fluid materials into Aluminum tube, plastic tube or composite tube. And then seal the tubes tail. Which machine adopts a new type dosing pump with stainless steel butterfly valve which matches with screw tiny adjustment outfit. Measure exactitude also in compliance with the standard of GMP requirement.  Adopt PLC program-able control as well as Photoelectricity identify outfit, orientation accurately and reliably, change frequency to control the machine speed, Used FuKaiShen index drives and international advanced tube sealing systems.

Key Features ◆Compact Design◆Driving Parts Fully-closed◆Pneumatic Tube Washing & Feeding◆Intelligent Temperature Control and Cooling System◆Easy to Operate and Adjust◆316L Stainless Steel Contact Parts to meet GMP Standard◆Safety Interlock Shutdown when Door is Open◆Overload Protection Provided◆Automated Working process from Tube Loading to Finished Products Output◆Automatic Orientation Effected by Photoelectric Induction Optional Devices ◆Chiller◆Date Coding Embossing◆Automatic Tube Feeding Magazine◆Change Parts Technical ParametersFilling volume：1-300ml/unit (Adjustable)Filling accuracy：≦±0.5﹪Capacity：3000-4800units/hour (Adjustable)Tube diameter：Φ10-50 mmTube length：210mm (can order)Hopper volume：40LEquipped motor：1.1KWMachine power：2kwDimension：22700×960×2100（mm）Power supply：380/220 (Optional)Weight：About1200 Kg

The tube filler with ultrasonic sealer is suitable for filling and sealing soft tubes. It is designed for products like toothpaste, creams, and cosmetics, cleaning products and washing products. Our ultrasonic sealer can be widely used for food products and medical and pharmaceutical industry goods.

1. Suitable for fluid no gas and filling semi liquid.2. Adopts PLC and touch screen control.3. The use of submersible filling.4. In accordance with GMP standard.
