Intelligent Electronic Counting Machine

PY-2B Intelligent Electronic Counting Machine is made by our company using the most advanced international vibration type channel feeding, oscillator stepless speed regulation, touch screen PLC intelligent control, optical fiber sensing probe counting, system self-test, automatic stop, and other advanced technology. The machine is made of stainless steel and designed according to GMP standards, and it is a high-tech pharmaceutical counting machine. It can be bottled, boxed and bagged and is fully compliant with GMP requirements, especially suitable for research institutes, hospitals, new small pharmaceutical plants and health care plants.

This machine is a quasi-tabletop type counting machine with reasonable design, compact structure, easy to use and high counting efficiency. It can be widely used in the fast counting bottling for a variety of different shapes and sizes of tablets, capsules, pills, transparent soft capsules and other drugs. The counting bottling accuracy has reached the advanced level of similar products at domestic and overseas.

Speed  800 - 2000 capsules/min

Application Scope  Hard capsules, soft capsules, tablets, pills, etc.

Control Method  Touch screen control

Counting Method  Fiber optic infrared detection

Applicable Size  Capsule Model  00#-5#

                   Tablet Diameter  5-25MM

Bottle Size  Diameter 25-75mm, Height≤180mm

Counting Errors  ±0.3%

Motor Power  110V～220V/50-60Hz /25W

Net Weight (kg)  50kg

External Dimensions  735mm×580MM×720MM

Machine Material  Stainless steel of main parts material 304(0Cr18Ni9）
